1 Die Head Accmulator Type Single Station Plastic Blow Molding Machine For Plastic Cleaning Tools
SLBC series: (German model) linear guide support single frame, finite element analysis of the design, to ensure adequate clamping force, not up
mode.
In the adjustment and debugging, the gap between the blow head slit and the die cut is adjusted by the adjusting nut on the blow pin cylinder; the
front and rear concentricity between the blow head cut and the die cut is through the needle holder and the blow Three M12 screws on the fixing
plate of the device are used to adjust the large offset amount. The left and right concentricity between the blow head slit and the die slit is
adjusted by the M12 screw on the needle holder and the fixed plate to adjust the large offset amount. The amount is adjusted by three M6
screws on the mounting plate. The guide column and the air blowing rod on the air blowing device must be refueled from time to time to make it
work normally.
| SPECIFICATION | SLBC-90 | |
| MATERIAL | PE,PP,EVA,ABS,PS | |
| MAX CONTAINER CAPACITY | L | 60 |
| OUPUT(DRY CYCLE) | PC/HR | 450 |
| MACHINE DIMENSION (LxWxH ) | MM | 6300x3400x4200 |
| TOTAL WEIGHT | TON | 14T |
| CLAMPING UNIT | ||
| CLAMPING FORCE | KN | 260 |
| PLATEN OPENING STROKE | MM | 400-1200 |
| PLATEN SIZE(WxH) | MM | 900x1000 |
| MAX MOULD SIZE(WxH) | MM | 750x1200 |
| MOLD THICKNESS | MM | 410-700 |
| EXTRUDER UNIT | ||
| SCREW DIAMETER | MM | 90 |
| SCREW L/D RATIO | L/D | 25 |
| MELTING CAPACITY | KG/HR | 140 |
| BARREL HEATING POWER | KW | 20 |
| NUMBER OF HEATING ZONE | ZONE | 5 |
| EXTRUDER MOTOR RATED POWER | KW | 45 |
| DIE HEAD | ||
| NUMBER OF DIE HEATING ZONE | ZONE | 4 |
| POWER OF DIE HEATING | KW | 18 |
| MAX DIE-PIN DIAMETER | MM | 400 |
| POWER | ||
| MAX DRIVE POWER | KW | 57 |
| TOTAL POWER | KW | 105 |
| FAN POWER OF SCREW | KW | 4 |
| AIR PRESSURE | MPA | 0.8-1.2 |
| AIR CONSUMPTION | M3/MIN | 0.8 |
| AVERAGE ENERGY CONSUMPTION | KW | 38 |
| ACCUMULATOR CAPACITY | L | 8 |
